Sprayer Pump Piston Diaphragm Pump AR 115 BP
1202AR
To order
Net price:
1.169,49 EUR
Gross price:
1.485,25 EUR
Product description
Usage
- Semi-hydraulic, low-pressure diaphragm pumps for herbicide and liquid manure spreading.
- The AR DUE, AR202, and AR252 pumps are horticultural diaphragm pumps.
Features
- Parts in contact with liquid are coated with plastic. For AR DUE, AR202, and AR252 pumps, these parts are made of anodized aluminum.
- The crankshaft drive operating in an oil bath is equipped with a sight glass (except AR DUE).
- Bolts with galvanic Dacromet protective treatment.
Technical Information
- SP: pump with universal shaft as drive shaft.
- Bp C: pump with PTO shaft, 1 3/8" - 6-spline.
- Bp C/C: pump with through shaft: double-sided PTO shaft, 1 3/8" - 6-spline - 1 3/8" - 6-spline.
- BpTwin: pump with through shaft: double-sided PTO shaft, 1 3/8" - 6-spline - 1 3/8" - 6-spline.
Includes
- Piston diaphragm pump with safety valve and air chamber (except AR DUE, AR202, and AR252).
- Pumps are supplied with rubber diaphragms as standard equipment.
Max. Flow Rate
108 l/min
Speed
1000 rpm
Max. Medium Temperature (continuous)
60 °C
Overall Length
340 mm
Height
293 mm
Motor Output Power
4.1 kW
Motor Power
5.6 HP
Weight
14 kg
Max. Pressure
20 bar
Diaphragm Material
NBR
Suction Side Connectio
We reserve the right to change the price (product price and delivery price)!
Image is for illustration purposes only!
