Plastic hydraulic hose reel 25m / Drum

Brand
Alfagomma
Description
Plastic hydraulic hose with 2 layers of high tensile steel wire mesh
Advantages
High ozone resistance
Extremely durable, abrasion-resistant outer coating (15x higher than the applicable standard)
Product data
High pressure hose
Compact rubber hydraulic hose with 2 layers of high tensile steel wire mesh
Smaller bending radius than standard compact hoses according to EN 857-2SC.
Mineral and glycol-based fluids, vegetable and mineral lubricants, crude oils, cooling water, compressed air, etc.
Practically complies with DIN 20022-2SN / EN857-2SC dimensions
Available lengths: 25 or 50 m rolls.
Uses
High-pressure hose
Standard hose for all applications, especially suitable for construction machinery and agricultural equipment
High ozone resistance makes it particularly suitable for road traffic
Mineral oil and glycol-based fluids, vegetable and mineral lubricants, crude oils, cooling water, compressed air, etc.
Properties
Basically corresponds to the dimensions according to DIN 20022-2SN / EN857-2SC
Extremely abrasion-resistant, ozone- and oil-resistant outer jacket
High resistance to ozone
Especially abrasion-resistant outer jacket (15 times the current standard)
Technical information
Delivery length: 25 or 50 m on hose reel
Product benefits
These compact hoses from the Flexopac series have a higher operating pressure and a smaller bending radius than standard compact hoses according to EN 857-2SC
Contents
Hose reel
One hose length.
Hose inner diameter
19 mm
Hose inner diameter
3/4 in
DN
19 mm
Hose outer diameter
27.6 mm
Max. working pressure
240 bar
Max. working pressure
24 MPa
Burst pressure
960 bar
Max. working temperature
100 °C
Min. working temperature
-40 °C
Weight
0.79 kg/m
Bending radius
121 mm
Length
25 m
EN standard
857 2SC
